APA Vision Evolution Sliding
The APA Vision Evolution Sliding Door System blends pioneering design with high-performance engineering to create expansive, light-filled living spaces. Engineered for wide spans and floor-to-ceiling glazing, this premium lift-and-slide solution delivers sleek aesthetics, smooth operation and superior insulation — making it perfect for contemporary homes prioritising indoor-outdoor flow.
Designed with minimal visible frames and elegant sightlines, the Vision Evolution system maximises glass area and views while maintaining robust structural performance and energy efficiency. Built from thermally broken aluminium profiles and advanced hardware components, it ensures comfort, security and longevity throughout the home.
Whether you’re spec’ing for a full home renovation or a premium extension, the APA Vision Evolution combines architectural impact with practical everyday performance, offering a refined door system without compromise.
For more information on our out APA Vision Evolution Sliding Door System, can get in touch with a member of our team here.
- Frame depth: Frame 160 mm / 248 mm triple track / 336 mm four-track
- Rise-and-slide mechanism with stainless-steel rollers for effortless operation
- Glazing options: double or triple glazing up to ~60 mm thickness
- Maximum sash size: width up to ~4,500 mm / height up to ~3,500 mm (model dependent)
- Air permeability: Class 4 (EN 12207) and equivalent local standards
- Water tightness: Class E1200+ (EN 12208) for premium weather resistance
- Wind resistance: Class C5 or higher (EN 12210) for large-span strength
- Acoustic insulation: up to ~43 dB depending on glass specification
- Flush threshold and optional pocket-sliding configuration for seamless indoor-outdoor transitions
- Over 200 RAL colours available in single or dual finish
| Thermal transmittance | Uw ≥ 0.88 (W/m²K) | |
| Acoustic insulation | Rw up to 43 dB | |
| Air permeability | Class 4 | |
| Water tightness | Class E900 | |
| Wind resistance | Class C5 | |
| Sections | Frame 160 mm / 248 mm triple track / 336 mm four-track | |
| Glazing | Max. 44 mm, Min. 28 mm | |
| Maximum sash weight | 500 kg |
